Unit 2

After you do question one in the above handout, do Activity 4.2.1 in "Computer Engineering" Pages 161 and 162
I will be testing the circuit (with you) and marking the questions for completion.
You will have to work in groups of 2. No more.

Do Exercise 4.2.3 in "Computer Engineering" using all 4 gates on your LS7408 chip


Page 148
1,2,3,4,5,7,9,11,12,13
then 14, 15, 20, 21
page 175
7

Chapter 3 of book

Half adder and Full adder

Page 192
1,2,3,4,5,6,7

Seven segment display

Exercise Page 234 to 239

555 Timer
Page 250 and 241


Meter Exercise

Operating Systems and Networks

Unit 4 programming using Python
